10-24V Single Power Supply Front Stage Board with Super Dynamic Bass Boost

This front stage audio board provides car audio enthusiasts with a dedicated solution for bass enhancement and signal processing. Operating on a single power supply from 10-24V DC, it integrates readily with various vehicle electrical systems without requiring complex power management. The board's super dynamic bass boost functionality targets the 22Hz-300Hz frequency range, offering control over low-end audio reproduction. With its compact dimensions and mono output configuration, it serves as a practical component for audio system builders looking to enhance their sound setup.

Features and Construction

The board's design prioritises both functionality and practical integration within audio systems. Its construction and specifications reflect attention to installation requirements and signal processing capabilities.

Material and Build

Constructed from super hardness FR-4 fiberglass board, the PCB provides reliable circuit protection while maintaining structural integrity. This material choice offers resistance to vibration and temperature variations common in vehicle environments. The board thickness measures 1.6 mm, balancing durability with weight considerations for a finished net weight of 30 grams.

Size and Practical Fit

Measuring 78 mm x 32 mm, the compact board dimensions allow installation in various vehicle locations with limited space. The plate fixing holes feature 70 mm x 24 mm centre spacing with 3.2 mm diameter holes for secure mounting. Potentiometer shaft centres are spaced 32.5 mm apart, accommodating standard component arrangements for adjustment accessibility.

Uses and Placement

This front stage board serves specific roles within audio system configurations, from professional installations to enthusiast projects.

Event or Professional Use

In professional audio setups, the board's 22Hz-300Hz frequency range control and bass boost functionality allow sound engineers to tailor low-end response. The mono audio output simplifies integration with amplification chains, while accepting both mono or dual channel audio input provides flexibility for various source configurations.

Everyday Home Use

For audio enthusiasts modifying home systems, the 10-24V single power supply operation reduces complexity compared to dual-supply designs. The board's compact 78 x 32 mm footprint facilitates installation in limited spaces within audio racks or equipment enclosures.

Benefits and Buying Value

The board offers practical advantages through its design approach and component integration.

Reuse and Low Maintenance

The FR-4 fiberglass construction provides durability for repeated handling during system modifications or upgrades. Standardised hole spacing and potentiometer layout support component replacement if required, extending the board's useful lifespan within evolving audio setups.

Why Choose This Product

This front stage board addresses specific audio processing needs with its focused bass boost functionality and flexible 10-24V power range. Unlike more complex systems requiring multiple power supplies, its single-supply design simplifies installation while maintaining signal processing capabilities. The combination of compact dimensions, defined mounting points, and clear audio specifications provides a straightforward solution for bass enhancement projects.
